4-5
Chapter 4: Chassis Setup and Maintenance
Note: For optional rear and internal drives, see section 4-12.
Installing a Hard Drive
1. Remove the two screws securing the dummy drive to the drive carrier and
remove the dummy drive.
2. Slide the hard drive into the carrier with the printed circuit board side facing down.
Figure 4-5. Removing a Dummy Drive from the Drive Carrier
Drive Carrier
Dummy Drive
1
1
