ioLogik 2500 Series Offline Configuration Management

4-30

Remote

• IP Address: The IP address of the remote device that collects and sends signals.

• Slot Index: An integer used to represent the remote ioLogik 2500 and its E1200 expansion units (0:

the ioLogik 2500 head unit; 1 to 8: the ioLogik E1200 expansion units).

• Module Type: The model name of the remote device.

• Channel Type: The input channel type of the remote device.

• Channel Index: The input channel index of the remote device.

Local

• Slot Index: The local ioLogik 2500 or its E1200 expansion units.

• Channel Type: The output channel type of the local device.

• Channel Index: The output channel index of the local device.

• Disconnection Mode: The output mode when peer-to-peer disconnection occurs (options for DO: ON,

OFF, or Hold Last; options for AO: manual or Hold Last).

Criterion

• On change: Triggers the peer-to-peer signal transmission when the status of the DI channel changes or

the value of the AI channel changes by the pre-defined percentage.

• Interval: Triggers the peer-to-peer signal transmission when the interval time elapses (500 to 65535

ms; default = 1000).

NOTE

Up to 16 P

eer-to-Peer rules can be set (a set of ioLogik 2500 + up to 8 x ioLogik E1200).

NOTE

You only need to configure peer

-to-peer rules for output channels on the local ioLogik device. The peer-to-

peer channel

s at the remote field site will be mapped to automatically.
