A. Network Port Usage
The ioLogik 2500 uses the following network ports:
Usage Type Port User-Defined
Serial Tunnel Client TCP 1
FTP Client TCP 21
FTP Server TCP 21
Web Console TCP 80
SNMP Server TCP 161
SNMP Client TCP 162
Modbus Communication TCP 502
SMTP TCP 587
Serial Tunnel Server TCP 4001
Auto Search Function UDP 4800
TCP/UDP Message
TCP 9000
UDP 9000
Remote Action Function TCP 9010
Peer-to-peer Function TCP 9300
IOxpress TCP 10124
AOPC Protocol*
TCP 9500
TCP 9900
*The ioLogik 2500 series only supports MX-AOPC UA server.
NOTE
•
Client refers to when the ioLogik 2500 is acting as a client to connect other services.
•
Server refers to when the ioLogik 2500 is acting as a server to provide services to other devices.
