ioLogik 2500 Series Cellular Network Setup and Configuration (for cellular models)

6-3

Cellular ON Demand

This mode allows the ioLogik 2500-GPRS/HSPA to conserve power by flipping into sleep mode whenever

there is no need to transmit information. When in sleep mode, the ioLogik 2500-GPRS/HSPA disables the

cellular connection and stays in standby mode, saving all I/O records in the data log on the SD card. The

ioLogik 2500-GPRS/HSPA will only wake up when either:

1. It receives an activate message from Click&Go, or

2. It receives a call from an authorized caller phone number.

LAN as Primary and Cellular as Backup

By selecting this function, a remote destination is used in this setting to indicate if the Internet connection

is still alive. The user can specify a public IP or URL and the number of retries that are allowed. If the

Ethernet is disconnected, the cellular connection will be triggered as a backup.

Dest IP/URL

This option, which can be configured to either an AOPC server IP or any public URL, will be used by the

device to determine whether or not it is connected to the Internet.

Continuous Check Until 3 failures

The ioLogik 2500-GPRS/HSPA continuously check its connection with the IP/URL to ensure that it is

constantly connected to the internet (could incur a high cost, depending on your cellular plan).

Retry Interval

The “retry interval” is the time interval between retries.

Cellular

Cellular network settings are configured on the “cellular” page, which is located under “Network.”

General

To set up your cellular connection, click the Cellular Settings tab and enter your User name, Password,

SIM pin code, and APN of your Cellular Provider (contact your local Cellular Service Provider for

assistance).
