ioLogik 2500 Series Cellular Network Setup and Configuration (for cellular models)

6-8

Port Forwarding

The ioLogik 2500-GPRS/HSPA supports port forwarding on its cellular and Ethernet interfaces for WAN-to-

LAN communication. Using port forwarding, the ioLogik 2500-GPRS/HSPA allows external WAN hosts such

as SCADA/HMI systems to connect to specific field devices within the LAN by linking with the ioLogik 2500-

GPRS/HSPA.

Ethernet packages from public ports will be forwarded to the assigned Internal IP and Internal Port. In the

example shown above, Ethernet packets from the ioLogik 2500’s port 80 will be forwarded to

192.168.127.50:8000 (IP: 192.168.127.50; Port: 8000).

Enable Port Forwarding

Enable or disable the port forwarding function.

Index

The port forwarding rules index for identification, cannot be changed.

Protocol

Choose which Ethernet protocol will be forwarded. You can choose either TCP or UDP.

Internal IP

The destination IP that Ethernet packets will be forwarded to.

Internal Port

The destination port that Ethernet packets will be forwarded to.
