ioLogik 2500 Series Cellular Network Setup and Configuration (for cellular models)

6-6

Local Identity

Identity option: Select additional ID authentication requirements for the VPN using a specific IP Address,

FQDN, or User FQDN settings.

IP/FQDN/User_FQDN: Enter an ID (IP/FQDN/User_FQDN) to identify and authenticate the local VPN

endpoint.

ISAKMP phase 1

Operation mode: Select main mode or aggressive mode to configure the standard negotiation parameters

for IKE Phase 1 of the VPN Tunnel.

NAT-T (default = Disable): Enabling this option will allow IPSec traffic from this endpoint to traverse

through the translation process during NAT. The remote VPN endpoint must also support this feature and it

must be enabled to function properly over the VPN.

Encryption mode: Select the VPN ISAKMP phase 1 encryption mode. Authentication mode: Select the

VPN ISAKMP phase 1 authentication mode. Diffie-Hellman group: Select the VPN ISAKMP phase 1 DH

group. As the DH Group number increases, the higher the level of encryption implemented for PFS.

SA life time (default = 86400): Enter the number of seconds for the VPN ISAKMP phase 1 Lifetime. This

is the period of time that passes before establishing a new IPSec security association (SA) with the remote

endpoint.

ISAKMP phase 2

Encryption mode: Select the VPN ISAKMP phase 2 encryption mode. Authentication mode: Select the

VPN ISAKMP phase 2 authentication mode.

Diffie-Hellman group: Select the VPN ISAKMP phase 2 DH group. As the DH Group number increases, the

higher the level of encryption implemented for PFS.

SA life time (default = 28800): Enter the number of seconds for the VPN ISAKMP phase 2 Lifetime. This

is the period of time that passes before establishing a new IPSec security association (SA) with the remote

endpoint.

Advanced settings

Anti-replay (default = Disable): Anti-replay is the method of not allowing an intercepted packet

message to be sent to the recipient multiple times without the original sender knowing about it.

Dead Peer Detection (DPD) (default = Disable): Enable or disable Dead Peer Detection. DPD is a

method of detecting a dead Internet Key Exchange (IKE) peer. It sends a DPD packet to the peer every 60

seconds under no traffic and attempts to connect normally. If the DPD packet fails 5 times the VPN will

continuously re-establish a connection.
