ioLogik 2500 Series Overview
1-4
Communication Interface
Model Name Communication Interface
ioLogik 2512
ioLogik 2542
Serial / Ethernet
ioLogik 2512-GPRS
ioLogik 2542-GPRS
Serial / Ethernet / GPRS (2G)
ioLogik 2512-HSPA
ioLogik 2542-HSPA
Serial / Ethernet / GPRS (2G) /HSPA (3G)
ioLogik 2512-WL1
ioLogik 2542-WL1
Serial / Ethernet / Wireless LAN
ioLogik 2500 Ethernet Series Specifications
Common Specifications
LAN
Ethernet:
• 4 switched 10/100 Mbps RJ45 ports
• 1 optimized port for faster downstream communications with
daisy-chained ioLogik E1200 units
Note: The optimized daisy
-chain port is not supported by the ioLogik E1261W-T, E1261H-T, or E1263H-T.
Protection:
1.5 kV magnetic isolation
Protocols:
Modbus/TCP (slave), TCP/IP, UDP, DHCP, BOOTP, SNMP, HTTP, CGI, SNTP, SMTP
Serial
Interface:
2 RS-232/422/485 (software selectable) RJ45 ports
Parity:
None, Odd, Even
Data Bits:
5, 6, 7, 8
Stop Bits:
1, 2
Flow Control:
None, RTS/CTS, XON/XOFF
Baudrate:
300 to 115200 bps
Protocols:
Modbus/RTU (master/gateway), serial tunnel mode (client/server)
Physical Characteristics
Wiring:
I/O cable max. 14 AWG
Dimensions:
61 x 157 x 115 mm (2.4 x 6.18 x 4.53 in)
Weight:
Under 1265 g (2.79 lb)
Mounting:
DIN-rail (standard), wall (with optional kit)
Storage
Expansion Slot:
Up to 32 GB microSD™ memory card (SDHC compatible)
Note: For units operating in extreme temperatures, industrial
-grade, wide-temperature SD cards are
required.
Environmental
Limits
Operating Temperature:
Standard Models:
-10 to 60°C (14 to 140°F)
Wide Temp. Models:
-40 to 75°C (-40 to 167°F)
Storage Temperature:
-40 to 85°C (-40 to 185°F)
Ambient Relative Humidity:
5 to 95% (non-condensing)
Shock:
IEC 60068-2-27
Vibration:
IEC 60068-2-6
Altitude:
Up to 2000 m
Note: Please contact Moxa if you require products guaranteed to function properly at higher altitudes.
