Chapter 1
Introduction
Overview
The CM0264 2x4 DVI-HD Audio/Video Matrix KVMP Switch charts a
revolutionary new direction in KVM switch functionality by combining a 2-
port HD audio/video KVM switch and a 2-port DVI KVM switch with a 2-port
USB 2.0 hub in a dual display console setup with a Graphical User Interface
(GUI) and a range of innovative desktop control features.
The CM0264 2x4 DVI-HD Audio/Video Matrix KVMP Switch’s Dual
Display Console supports one DVI display and one HD audio/video display,
allowing users to access 4 computers/devices from a single console, consisting
of USB keyboard, USB mouse, and one or two displays. As USB hub, it
permits each computer to access connected peripherals on a one-computer-at-
a-time basis.
As a matrix switch, the CM0264 enables effortless switching between two DVI
sources and two HD audio/video sources via hotkeys, pushbuttons, mouse, and
GUI. In addition, with support for two console displays, the CM0264 offers
3n1 picture-in-picture view mode that allows you to monitor up to four
computers simultaneously. Further innovative desktop control features include
on-screen file transfer and copy-paste functionality, as well as Cursor Shift port
switching in dual-display mode.
Recognizing the increased importance of digital audio, the CM0264’s two HD
audio/video interfaces integrate multi-channel audio support that allows users
to experience high-definition audio such as Dolby True HD and DTS HD
Master Audio. Furthermore, a single microphone can provide audio input to
each of the computers, and you can listen to the audio output of each computer
on a single set of speakers (on a one-at-a-time basis). As with the USB
peripherals, the audio focus can be independent of the KVM focus.
With its unique design and innovative features, the CubiQ CM0264 2x4 DVI-
HD Audio/Video Matrix KVMP Switch provides both style and functionality
for the SOHO environment. Allowing you to switch seamlessly between two
HD audio/video- and two DVI-enabled PCs, and share USB peripherals and
high-definition audio from a dual-display console, the CM0264 is ideal for
multimedia applications, and offers the ultimate in space-saving, streamlined
KVM technology for the desktop.
