CM0264 User Manual

3n1 View Desktop Control and Monitoring

Matrix Windows

As a matrix KVM switch, the CM0264 allows you to monitor the video output

of up to four PCs on up to two displays with its innovative 3n1 View desktop

control and monitoring function. When the CM0264’s GUI is operational, the

desktop environment of up to three additional PCs appear in their own matrix

windows. The default operation setting is the first powered-on computer’s

video output displayed fully with the video output of the other ports displayed

vertically in smaller matrix windows to the right of the screen, as below:

The position and appearance of these matrix windows is fully customizable –

they can be minimized/maximized, moved, and hidden. See the following

pages for details.

Non-PC Devices

Only computer operating systems are displayed by the CM0264’s 3n1 View

function. If you have a non-PC device, such as a DVD player, connected to

either HD audio/video port, for example, its display will not appear as a matrix

window in the GUI. To switch to this non-PC display, use the unit’s front panel

pushbuttons (see Manual Switching, page 15) or keyboard hotkeys (see Port

Switching, page 21).
