CM0264 User Manual
64
Factory Default Hotkeys and Settings
Setting Hotkey Default
Port Switching (Default / Alternate) [T] [Scroll Lock] [Scroll Lock]
Invoking HSM [H] [Number Lock] [-]
Auto Scan Interval [Scroll Lock]
[Scroll Lock]
[A] [Enter]
5 seconds
Keyboard Operating Platform [F10] PC Compatible
Mouse Emulation [M] Enabled
Keyboard Emulation [N] Enabled
Cursor Shift Function [W] Disabled
Port Switching Keys (On / Off) [X] [Enter] Enabled
Buzzer [B] Enabled
Power on Detection [E] Enabled
Keyboard Language [F6] [nn] [Enter]
Note: nn is the
language number
English
Limited Warranty
IN NO EVENT SHALL THE DIRECT VENDOR'S LIABILITY EXCEED THE PRICE PAID
FOR THE PRODUCT FROM DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THE PRODUCT, DISK,
OR ITS DOCUMENTATION.
The direct vendor makes no warranty or representation, expressed, implied, or statutory with
respect to the contents or use of this documentation, and especially disclaims its quality,
performance, merchantability, or fitness for any particular purpose.
The direct vendor also reserves the right to revise or update the device or
documentation without obligation to notify any individual or entity of such
revisions, or update. For further inquiries, please contact your direct vendor.
