CM0264 User Manual
44
Basic Functions
Navigation
Navigating the matrix windows and moving them around in the CM0264’s 3n1
View function is quick and easy, as follows:
To bring a matrix window display to full screen:
a) Double click the title bar or inside the matrix window of the display you
wish to enlarge;
b) Use the standard Windows maximize/minimize functions.
Note: Maximizing the matrix window is a port switching function.
Keyboard and mouse focus switch along with the video display. See
3n1 View Desktop Control and Monitoring, page 42, for further
details.
To minimize all matrix windows, click the Hide Matrix Windows icon in
the GUI’s main toolbar.
Note: The Hide Matrix Windows function hides all the matrix windows.
Use the standard Windows maximize/minimize function to hide
individual matrix windows.
To move a matrix window, click on the window’s toolbar and drag to a
convenient location on your desktop.
