![Aten CM0264 [34/74] Going directly to a port](/views2/1211091/page34/bg22.png)
CM0264 User Manual
24
Going Directly to a Port
Hotkey Action
[Scroll Lock] [Scroll Lock]
[n] [Enter]
Brings the KVM1, USB hub, and audio focus to the
computer attached to the specified port.
If the V2 focus is on the specified port when this hotkey is
used, the V2 focus switches with the original KVM1 focus.
If the V2 focus is on any other port than the specified one,
it remains where it is.
Note: Use this hotkey to bring complete control via the current
display to a specific computer/device.
[Scroll Lock] [Scroll Lock]
[n] [V] [S] [U] [Enter]
Brings the V2, USB hub, and audio focus to the computer
attached to the specified port. The KVM1 focus remains
where it is.
Note: Use this hotkey to bring complete control via the other
display to a specific computer/device.
[Scroll Lock] [Scroll Lock]
[n] [K] [Enter]
Brings only the KVM1 focus to the computer attached to
the specified port. The V2, USB hub, and audio focus
remain where they are.
Note: Use this hotkey to bring KVM control via the current display
to a specific computer/device.
[Scroll Lock] [Scroll Lock]
[n] [V] [Enter]
Brings only the V2 focus to the computer attached to
specified port. The KVM1, USB hub, and audio focus
remain where they are.
Note: Use this hotkey to bring video via the other display to a
specific computer/device.
[Scroll Lock] [Scroll Lock]
[n] [U] [Enter]
Brings only the USB hub focus to the computer attached
to the specified port. The KVM1, V2, and audio focus
remain where they are.
[Scroll Lock] [Scroll Lock]
[n] [S] [Enter]
Brings only the audio focus to the computer attached to
the specified port. The KVM1, V2, and USB hub focus
remain where they are.
[Scroll Lock] [Scroll Lock]
[n] [K] [U] [Enter]
Brings the KVM1 and USB hub focus to the computer
attached to the specified port. The V2 and Audio focus
remain where they are.
Note: Use this hotkey to bring KVM and USB control via the
current display to a specific computer/device.
[Scroll Lock] [Scroll Lock]
[n] [V] [U] [Enter]
Brings the V2 and USB hub focus to the computer
attached to the specified port. The KVM1 and Audio focus
remain where they are.
Note: Use this hotkey to bring video and USB control via the other
display to a specific computer/device.
