Aten CM0264 [23/74] Basic operation
![Aten CM0264 [23/74] Basic operation](/views2/1211091/page23/bg17.png)
13
Chapter 3
Basic Operation
Overview
There are four convenient methods to access the computers: manual, hotkey,
Cursor Shift, and Matrix Windows in the Graphical User Interface (GUI).
Manual operation involves pressing the Mode and port selection pushbuttons
located on the unit’s front panel. This is discussed in this chapter. Hotkey
operation, which involves entering combinations from the keyboard, is
discussed in Chapter 4. Port switching via Cursor Shift and Matrix Windows
in the GUI are discussed in Chapter 5.
Default Display and Power On Sequence
The CM0264’s default display is the DVI display. The first powered-on
computer or device displays on the DVI display and has the default KVM
focus. This means that, if an HD audio/video computer/device attached to Port
2, for example, is powered on first, it has the default KVM focus but displays
on the DVI display*. Therefore, we recommend that your computers/devices
are powered on in sequence, starting with the computer/device attached to Port
1 and ending with the computer/device attached to Port 4.
* An HD audio/video computer/device displays video on a DVI display, but
HD audio/video audio is not supported.
Non-PC Devices
Non-PC devices, such as DVD players, can only be accessed using the
CM0264’s front panel pushbuttons (see Manual Switching, page 15) or
keyboard hotkeys (see Port Switching, page 21). Furthermore, as non-PC
devices cannot have complete KVM focus (only video), see Switching the Non-
KVM Video, page 18 for further details.
