![Aten CM0264 [68/74] Specifications](/views2/1211091/page68/bg44.png)
CM0264 User Manual
58
Specifications
Function CM0264
Computer Connections 4
Port Selection Front Panel Pushbuttons; Hotkeys; GUI
Connectors Console
Ports
KB 1 x USB Type A Female (Black; rear panel)
Video 1 1 x DVI-I Female (White)
Video 2 1 x HD audio/video Type A Female (Black)
Mouse 1 x USB Type A Female (Black; rear panel)
Speaker
2 x Mini Stereo Jack Female (Green; 1 x front, 1 x rear)
Mic.
2 x Mini Stereo Jack Female (Pink; 1 x front, 1 x rear)
KVM
Ports
KB/
Mouse
4 x USB Type B Female (White)
Video 2 x HD audio/video Type A Female (Black);
2 x DVI-I Female (White)
Speaker 4 x Mini Stereo Jack Female (Green)
Mic. 4 x Mini Stereo Jack Female (Pink)
Power 1 x DC Jack
USB 2.0 Hub 2 x USB Type A Female (White; 1 x front panel; 1 x
rear panel)
Switches Selected 5 x Pushbutton
LEDs KVM 5 (Orange/Green)
Audio 5 (Green)
USB 5 (Green)
Emulation Keyboard / Mouse USB
Video 1080p (HD audio/video) / 1920 x 1200 (DVI)
Scan Interval 1–99 secs. (Default: 5 secs)
Power Consumption DC 5.3V, 10W
Environment Operating Temp. 0–50ºC
Storage Temp. -20–60ºC
Humidity 0–80% RH, Non-condensing
Physical
Properties
Housing Metal
Weight 0.86 kg
Dimensions
(L x W x
H)
26.00 x 7.50 x 4.50 cm
