Chapter 4. Keyboard Port Operation

Keyboard Emulation Control

Console keyboard port emulation/bypass feature supports most gaming/

multimedia keyboards. The default setting is enabled. To disable, do the

following:

1. Invoke HSM (see page 27

2. Press [N].

This procedure is a toggle. Repeat to enable.

Note: When keyboard emulation is off, the [m], [w], [F2], [F4], [F5], [F6], and

[F10] hotkeys are disabled. See page 32, for details.

Mouse Emulation Control

The default setting is enabled. To disable, do the following:

1. Invoke HSM (see page 27

2. Press [M].

This procedure is a toggle. Repeat to enable.

Cursor Shift Port Switching

When you are using two displays, the Cursor Shift function allows the mouse

cursor to move back and forth across both displays, shifting the KVM focus

(See Cursor Shift, page 46. for details). The default setting is disabled. To

enable, do the following:

1. Invoke HSM (see page 27

2. Press [W].

This procedure is a toggle. Repeat to disable.

Note: This function is only available when mouse emulation and keyboard

emulation are enabled.

SPC Mode

To set the keyboard/mouse to use SPC mode so that it can work under special

operating systems as a standard (104 key) keyboard/mouse, do the following:

1. Invoke HSM (see page 27).

2. Press [F1].
