Aten CM0264 [19/74] Hardware setup

Chapter 2

Hardware Setup

Cable Connection

To set up your CM0264 installation, refer to the installation diagram on

page 11 (the numbers in the diagrams correspond to the steps, below), and do

the following:

1. Plug your USB keyboard and USB mouse into the USB Console Ports

located on the unit’s rear panel.

2. Plug your DVI display into the Console DVI-I Single Link Port located on

the unit’s rear panel.

3. Plug your HD audio/video display into the Console HD audio/video Port

located on the unit’s rear panel.

4. If you are using an IP phone headset or separate microphone and speakers,

plug them into the analog audio ports on the unit’s front panel. These

audio ports have priority over those on the rear panel.

5. If you are using separate speakers and microphone, plug them into the

console analog audio ports on the unit’s rear panel.

6. Using the custom DVI KVM cable set, plug the DVI-D Single Link cable

connector and the accompanying USB and audio connectors their

corresponding sockets on the rear of the switch.

7. At the other end of the cable, plug the DVI and USB cables into their

respective ports on the computer(s) that is(are) the source of DVI content.

(Continues on next page.)

1. Important safety information regarding the placement of this

device is provided on page 55. Please review it before

proceeding.

2. Make sure that the power to all devices connected to the

installation is turned off. You must unplug the power cords of

any computers that have the Keyboard Power On function.
