Chapter 3. Basic Operation
17
Dual Display Console
In Dual Display Console mode, the CM0264 supports both a DVI and an HD
audio/video display, and it is possible for either monitor to have the current
KVM focus, while the other has video focus only. In following section, KVM1
refers to KVM focus via the current console display; V2 refers to video only
focus on the other monitor.
Note: The KVM1 LED lights orange; the V2 LED lights green.
To bring complete focus (audio, KVM1 and USB) to a computer, either,
a) press the port selection pushbutton that corresponds to that computer; or
b) press the Mode pushbutton once (the Mode pushbutton’s three icons
light up) and then press the port selection pushbutton that corresponds to
that computer. All three port icons light up.
To bring only the KVM1 focus to a computer, press the Mode pushbutton
twice (the Mode pushbutton’s KVM icon lights up), and then press the
port selection pushbutton that corresponds to that computer. The port’s
KVM icon (the port number) lights up.
To bring only the V2 focus to a computer, press the Mode pushbutton
three times (the Mode pushbutton’s KVM icon lights up), and then press
the port selection pushbutton that corresponds to that computer. The port’s
KVM icon (the port number) lights up.
To bring only the audio focus to a computer, press the Mode pushbutton
four times (the Mode pushbutton’s audio icon lights up), and then press
the port selection pushbutton that corresponds to that computer. The port’s
audio icon lights up.
To bring only the USB focus to a computer, press the Mode pushbutton
five times (the Mode pushbutton’s USB icon lights up), and then press the
port selection pushbutton that corresponds to that computer. The port’s
USB icon lights up.
Press and hold port selection pushbuttons 1 and 2 simultaneously for 2
seconds to start Auto Scan Mode, see Auto Scanning, page 26 for details.
Note: Press and release either port selection pushbutton to stop Auto Scan
Mode. The KVM focus goes to the port you pressed.
Press and hold port selection pushbuttons 3 and 4 simultaneously for 2
seconds to execute a KVM reset. See KVM Reset, page 19 for details.
