CM0264 User Manual

Power on Detection

With Power on Detection if the focus computer is powered off, the switch will

automatically switch to the next powered-on computer. Power on Detection

can be enabled or disabled. The default setting is enabled. To disable Power on

Detection, do the following:

1. Invoke HSM (see page 27).

2. Press [E].

This setting is a toggle. Repeat to enable.
