![Aten CM0264 [32/74] Going directly to a port](/views2/1211091/page32/bg20.png)
CM0264 User Manual
22
Going Directly to a Port
Note: The n stands for the computer’s Port ID number (1, 2, 3, or 4). See KVM
Reset, page 19, for details. Replace the n with the appropriate Port ID
when entering hotkey combinations.
Hotkey Action
[Scroll Lock] [Scroll Lock]
[n] [Enter]
Brings the KVM, USB hub, and audio focus to the
computer attached to the port corresponding to the
specified Port ID.
[Scroll Lock] [Scroll Lock]
[n] [K] [Enter]
Brings only the KVM focus to the computer attached to
the specified port. The USB hub and audio focus remain
where they are.
[Scroll Lock] [Scroll Lock]
[n] [U] [Enter]
Brings only the USB hub focus to the computer attached
to the specified port. The KVM and audio focus remain
where they are.
[Scroll Lock] [Scroll Lock]
[n] [S] [Enter]
Brings only the audio focus to the computer attached to
the specified port. The KVM and USB hub focus remain
where they are.
[Scroll Lock] [Scroll Lock]
[n] [K] [U] [Enter]
Brings the KVM and USB hub focus to the computer
attached to the specified port. The audio focus remains
where it is.
[Scroll Lock] [Scroll Lock]
[n] [K] [S] [Enter]
Brings the KVM and audio focus to the computer
attached to the specified port. The USB hub focus
remains where it is.
[Scroll Lock] [Scroll Lock]
[n] [U] [S] [Enter]
Brings the USB hub and audio focus to the computer
attached to the specified port. The KVM focus remains
where it is.
