CM0264 User Manual
6
No. Component Description
1 LED Status Panel This panel contains LED icons that light to indicate mode
and port status. The Mode and Port Selection Pushbuttons
each have three corresponding LED icons that represent
audio, KVM1/V2, and USB status. See LED Display,
page 14, for full details.
2 Port Selection
Pushbuttons
Press the Port Selection Pushbuttons to manually
switch ports. See Manual Switching, page 15, for full
details.
Press and hold Port Selection Pushbuttons 1 and 2
simultaneously for 2 seconds to start Auto Scan Mode.
See Going Directly to a Port, page 24, for full details.
Press and hold Port Selection Pushbuttons 3 and 4
simultaneously for 2 seconds to execute a KVM reset.
See KVM Reset, page 19 for full details.
3 Mode Selection
Pushbutton
This pushbutton allows you to cycle through the three
modes of focus – KVM1/V2, audio, and USB.
Press and hold Mode Selection Pushbutton before
powering on the CM0264 to enter Firmware Upgrade
Mode. See Starting the Upgrade, page 50 for full details.
4 Console Audio
Ports
Your speakers and microphone plug in here.
5 USB 2.0
Peripheral Port
USB 2.0 peripherals (printers, scanners, etc.) plug into this
port.
