HU A konzol (9) nyeregvázcső-
ről való eltávolításához csavarja ki
a négy csavart (15).
IT Rimuovere la staffa (9) dal
telaio della bicicletta svitando le
quattro viti facilmente accessibili
montate sulla parte anteriore(15).
JA ブラケット（9）をサイクルフレー
ムから取り外すにはネジ4個を（15）を緩
めます。ネジが前面にあるので作業が簡
単です。
KO 쉽게 액세스 가능한 네 개의
전면 장착 나사(15)를 풀어 자전거
프레임에서 브래킷(9)을 분리합니다.
LT Nuimkite laikiklį (9) nuo
dviračio rėmo atsukdami keturis
laisvai pasiekiamus priekyje
tvirtinamus varžtus (15).
LV Noņemiet skavu (9) no
velosipēda rāmja, atskrūvējot abas
priekšpusē uzstādītās skrūves (15)
(tām var ļoti viegli piekļūt).
NL Verwijder de klem (9)
van het fietsframe door de
vier gemakkelijk toegankelijke
schroeven (15) die aan de
voorkant zijn gemonteerd, eraf
teschroeven.
NO Du fjerner braketten (9) fra
sykkelrammen ved å løsne de fire
frontmonterte skruene (15).
PL Zdejmij uchwyt (9) z ramy
roweru, odkręcając cztery łatwo
dostępne śruby z przodu (15).
PT Remova o fixador (9)
do quadro da bicicleta ao
desparafusar os quatro parafusos
frontais facilmente acessíveis (15).
RO Îndepărtaţi consola (9)
de pe cadrul bicicletei prin
deșurubarea celor patru șuruburi
din faţă.
RU Снимите опору (9) с
велосипедной рамы, отвинтив
четыре пеpeдних винта (15).
SK Odstráňte svorku (9) z
rámu bicykla odskrutkovaním
štyroch ľahko prístupných skrutiek
z prednej strany (15).
SL Odstranite kolesarski
prtljažnik (9) z okvirja kolesa tako,
da odvijete štiri zlahka dostopne
vijake na sprednji strani (15).
SV Du kan ta bort beslaget (9)
från cykelramen genom att skruva
ur de fyra skruvar som sitter lätt
åtkomliga på beslagets framsida
(15).
TH ถอดขายึด (9) ออกจากเฟรมรถ
จักรยาน โดยคลายสกรูยึดส่วนหน้าสี่ตัวที่
เข้าถึงได้ง่าย (15)
TR Kolayca erişilebilen önden
takılı dört vidayı (15) sökerek,
bağlantı parçasını (9) bisiklet
kadrosundan çıkarabilirsiniz.
UK Зніміть кронштейн (9) із
рами велосипеда, відкрутивши на
внутрішньому боці чотири гвинти
(15), до яких дуже легко дістатися.
ZH 拧开四个正面安装螺丝(15)即
可将托座(9)从自行车架上拆除。
