HE
HR/BIH Ako je sjedalo bicikla
postavljeno prenisko da bi se dječja
sjedalica za bicikl mogla sigurno
montirati, adapter niskog sjedala
dostupan je kao opcionalni dodatak.
HU Ha a kerékpárnyereg túl
alacsonyan van a kerékpár-gy-
erekülés biztonságos rögzítéséhez,
a külön megvásárolható alacsony
nyergekhez való kiegészítő adapt-
er használata ajánlott.
IT Se il sellino è posizionato
troppo in basso per montare in
tutta sicurezza il seggiolino da
bicicletta per bambini, è possibile
utilizzare l’adattatore per sellini
bassi opzionale.
JA サイクルのサドルが低すぎて子供
用のサイクルシートを安全に取り付けられ
な い 場 合 は 、オ プ シ ョ ン ア ク セ サ リ ー と し
て低いサドル用のアダプターをご用意して
います。
KO 자전거 안장이 너무 낮게
배치되어 어린이 자전거 좌석을
안전하게 장착할 수 없는 경우를
위해 낮은 안장 아답터가 선택 사양
액세서리로 제공됩니다.
LT Jeigu dviračio balnelis
nustatytas per žemai, kad būtų
galima saugiai tvirtinti vaiko
kėdutę, naudokite papildomą
balnelio adapterio priedą.
LV Ja velosipēda sēdeklis ir
novietots pārāk zemu, un tāpēc
bērnu sēdekļa uzstādīšana nav
droša, kā izvēles piederums var
būt zema sēdekļa adapteris.
NL Indien uw fietszadel te laag
zit om de kinderstoel er veilig op te
monteren, is de adapter voor lage
zadels een optionele accessoire.
NO Dersom sykkelsetet er
justert så lavt at barnesetet ikke
kan monteres på en trygg måte,
kan du bruke adapteren for lave
sykkelseter, som er ekstrautstyr.
PL Jeśli siodełko roweru
jest ustawione za nisko, by
bezpiecznie zamontować fotelik,
można zastosować specjalnie
wyprofilowany pałąk dostępny
oddzielnie.
PT Se o banco da sua bicicleta
for posicionado muito baixo para
permitir que o assento infantil
seja montado com segurança,
o adaptador para selim baixo,
um acessório opcional, pode ser
usado com essa finalidade.
RO Dacă şaua bicicletei este
poziţionată prea jos pentru a
permite montarea în siguranţă a
scaunului pentru copil, adaptorul
inferior pentru şa este un
accesoriu opţional.
RU Если седло велосипеда
расположено слишком низко, что
не позволяет безопасно закрепить
детское сиденье, рекомендуется
использовать дополнительный
адаптер для низкого седла.
SK Ak máte sedadlo bicykla
príliš nízko na bezpečnú montáž
detskej cyklosedačky, voliteľným
príslušenstvom je adaptér na
nízke sedadlo.
SL V primeru, da je sedež
vašega kolesa nameščen prenizko,
da bi lahko varno namestili otroški
sedež, je na voljo adapter za nizek
sedež.
SV Om cykelns sadel är så
lågt placerad att barnsätet inte
kan monteras säkert kan adaptern
för låga sadlar (extra tillbehör)
användas.
TH ถ้าอานจักรยานอยู่ต่ำาเกินกว่าจะ
ติดตั้งเก้าอี้จักรยานเด็กได้อย่างปลอดภัย
ให้ใช้อะแดปเตอร์สำาหรับอานต่ำาที่เป็น
อุปกรณ์เสริม
TR Bisiklet seleniz çocuk
bisiklet koltuğunun güvenli
bir şekilde monte edilmesine
olanak vermek üzere çok düşüğe
ayarlıysa, düşük sele adaptörü
opsiyonel bir aksesuar olarak
kullanılabilir.
UK Якщо висота сідла вашого
велосипеда замала для безпечного
кріплення дитячого крісла, у
пригоді стане перехідник для
низьких сідел, який можна замовити
додатково.
ZH 如果您的自行车车座过低,无
法安全安装儿童自行车座椅,您可以选
择可选附件低车座适配器。
אלו ידמ ךומנ םיינפואה בשומ םא
ןתינ ,דליל בשומה לש חוטב רוביח רשפאמ
םאתמ לש ילנויצפואה רזיבאב שמתשהל
.ךומנה בשומה
