NL
1 Comfortabele gordel
2 Gordellengteversteller
3 Veiligheidsgordel
4 Neerklapbare voetbandjes
5 Voetensteun
6 Kantelverstelling
7 Wasbare bekleding
8 Draagstang
9 Klem voor diverse fietstypes
10 Lengteverstelling
11 Gordelhoogteverstelling
12 Reflector
13 Voetensteunverstelling
14 Beschermstrook
NO
1 Behagelige festeseler
2 Lengdejustering for festeseler
3 Låsespenne
4 Nedfellbare fotstropper
5 Fotstøtte
6 Vinkeljustering
7 Vaskbar polstring
8 Bærebøyle
9 Brakett som passert til ulike
sykkeltyper
10 Lengdejustering
11 Høydejustering for festesele
12 Refleks
13 Høydejustering for fotstøtte
14 Håndbeskytter
PL
1 Komfortowe szelki
2 Regulator długości szelek
3 Klamra zabezpieczająca
4 Składane zapięcia stóp
5 Podnóżki
6 Regulator kąta odchylenia
7 Wyściółka do prania w pralce
8 Pałąk mocujący
9 Uchwyt do rowerów różnego
typu
10 Regulator położenia
wzdłużnego
11 Regulator wysokości szelek
12 Element odblaskowy
13 Regulator wysokości
podnóżków
14 Profil ochronny
PT
1 Cinto confortável
2 Regulador de comprimento do
cinto
3 Fivela de segurança
4 Tira para pés ajustável
5 Apoio para os pés
6 Regulador para inclinação
7 Forro lavável
8 Barra de suporte
9 Fixador para vários tipos de
bicicletas
10 Regulador para comprimento
11 Regulador de altura do cinto
12 Refletor
13 Regulador de altura do apoio
para os pés
14 Asa de proteção
RO
1 Centură confortabilă
2 Ajustor pe lungime al centurii
3 Cataramă de siguranţă
4 Benzi de fixare pliabile
5 Suport pentru picior
6 Ajustor cu înclinare
7 Căptuşeală lavabilă
8 Bară suport
9 Consolă pentru multe tipuri de
biciclete
10 Ajustor pe lungime
11 Ajustor pe înălţime al centurii
12 Reflector
13 Ajustor pe înălţime al
suportului pentru picior
14 Aripă de protecţie
RU
1 Удобный ремень безопасности
2 Устройство для регулировки
длины ремня безопасности
3 Замок ремня безопасности
4 Откидные фиксаторы для ног
5 Опора для ноги
6 Регулятор поперечного наклона
7 Моющаяся подкладка
8 Опорная дуга
9 Опора для разных типов
велосипедов
10 Устройство для регулировки
длины
11 Устройство для регулировки
высоты крепления ремня
безопасности
12 Рефлектор
13 Устройство для регулировки
высоты опоры для ноги
14 Защитный выступ
