GRAPHITE 59G824 [26/232] Preparation for operation

MEANING OF SYMBOLS

CAUTION

WARNING

ASSEMBLY/SETTINGS

INFORMATION

EQUIPMENT AND ACCESSORIES

Leg - 4 pcs1.

Screw + leg locking knob - 4 sets2.

Fence - 1 pce3.

Screw + washer - 2 sets 4.

Vertical clamp - 1 pce5.

Cutting blade shield - 1 pce6.

Mitre gauge - 1 pce7.

Ripping fence - 1 pce8.

Push stick - 1 pce9.

Dust bag - 1 pce10.

Screw + nut - 1 set11.

Hexagonal key - 2 pcs12.

PREPARATION FOR OPERATION

Remove power cord plug from mains socket before working at the device.

Flip over saw is supplied disassembled. Take items out of the package and assemble in the below described

order.

FLIP OVER SAW ASSEMBLY

● Tilt the saw slightly to the side.

Use the screws and leg locking knobs ( ● 21) (included) to attach the legs (22) to the base (g. A).

Set up the adjustable feet ( ● 23) so the ip over saw stands rmly.

DUST EXTRACTION

To install the dust bag (39) slide it rmly onto the dust extraction outlet (40) (when operating in mitre saw

mode) (g. B). To empty the dust bag (39), remove it from the dust extraction outlet (40) and open the zip-

fastener that allows to access inside the bag. Whenever more ecient dust extraction is required especially

for health hazardous carcinogenic dusts, attach hose of suction device directly to the dust extraction outlet

(40) (when using in table saw mode) or outlet in the cutting blade bottom shield (7) (when using in mitre

saw mode).

Empty the dust bag on a regular basis to avoid overll. To achieve optimal dust extraction empty the

bag when it is 2/3 full.

INSTALLATION AND REMOVAL OF CUTTING BLADE BOTTOM SHIELD

When in mitre saw mode, the cutting blade bottom shield must be installed to cover lower part of the

cutting blade.

● Install the cutting blade bottom shield (7) and fasten with screws (g. C).

Remove the cutting blade bottom shield ( ● 7) before operating in table saw mode.

TRANSPORT

Before moving the tool follow the procedure:

Set up the tool in table saw mode. ●
