GRAPHITE 59G824 [31/232] Operation and maintenance

When using standard angle quick setup, the pawl should clearly sound snapping into the groove.

SETTING SAW ARM HEAD FOR BEVEL CUTTING

Saw arm can be tilted at any angle within the range 0

to 45

for bevel cutting (g. T).

Pull the head locking pin ( ● 31) that releases saw arm and allow the saw arm to lift slowly to upper

position.

Loosen the locking lever for cutting blade tilt ( ● 6).

Tilt the saw arm left to desired angle that you can read on the angle scale for cutting blade tilt ( ● 25) (g. U).

Tighten the locking lever for cutting blade tilt ( ● 6).

If you need to set both angles (in both planes, horizontal and vertical) for compound cutting, always

set the bevel angle rst.

CHECKING AND ADJUSTMENT OF PERPENDICULAR POSITION OF CUTTING BLADE AND WORK

TABLE

To guarantee precise cuts, check basic setup parameters of the saw after some time of operation and readjust

if necessary.

● Loosen the locking lever for cutting blade tilt (6).

Set the head in the extreme right position (perpendicular to the turntable) and tighten the locking lever ●

for cutting blade tilt (6) (g. U).

Loosen the table rotation locking knob ( ● 32).

Set the turntable ( ● 34) in 0

position and tighten the table rotation locking knob (32).

Press the movable shield locking lever ( ● 42) and lower the saw head to the extreme down position.

Use the tool to check perpendicularity of cutting blade and the turntable ( ● 34).

When making measurements make sure that measurement device does not touch any cutting blade

tooth, otherwise the measurement may be inaccurate due to thickness of sintered carbide insert.

In case the measurement angle is dierent than 90

, the following adjustment is necessary:

Tilt the saw head to the left. ●

Turn the adjustment screw ( ● b) (g. U) clockwise or counter-clockwise to increase or decrease cutting blade

(30) tilt angle.

After perpendicular position of cutting blade and the work table has been set, allow the head to return ●

to its upper position.

Carry out similar adjustment for 45

head bevel angle, using adjustment screw (c) (g. W) located on the

opposite side of the saw arm.

OPERATION AND MAINTENANCE

Unplug the power cord from mains socket before commencing any activities related to installation,

adjustment, repair or maintenance.

CLEANING

● When the work is nished, remove thoroughly all pieces of material, scobs and dust from the work table,

area around cutting blade and its shield.

Clean the saw with brush or stream of compressed air. ●

Never use water or other chemical liquids for cleaning the saw. ●

Clean ventilation holes regularly to prevent motor overheating. ●

Store the saw in a dry place, beyond reach of children. ●

Entrust replacement of power cord and other repairs only to authorized service workshop. ●

Regularly check that all bolts and xing screws are tightened. They may get loosened after some

time of operation.
