Hyundai HL740-7 [153/165] Charging circuit

7-11

Engine

Running

Key switch

Check point

① - GND (Battery)

② - GND (Battery relay)

③ - GND (ALT B

)

④ - GND (ALT I)

⑤ - GND (Controller)

⑥ - GND (Fuse box)

Voltage

20~28V

4. CHARGING CIRCUIT

When the starter is activated and the engine is started, the operator releases the key switch to the

ON position.

Charging current generated by operating alternator flows into the battery through the battery

relay(CR-1).

The current also flows from alternator to each electrical component and controller through the fuse

box.

OPERATING FLOW

Warning flow

Altermator [CN-74(I)] I/conn [CN-4(8)] I/conn [CN-3(4)] Controller [CN-58(25)]

Cluster charge warning lamp ON

Charging flow

Alternator Starter [CN-45(B

)] Battery relay [CR-1]

Battery(+) terminal Charging

I/conn [CN-60(1),(2)] I/conn [CN-1(1),(2)] Fuse box

CHECK POINT

(1)

(2)

※ GND : Ground
