DGS-3212SR Stackable Gigabit Layer 2 Switch

CPU Utilization

This CPU Utilization window displays the moving average of the CPU.

To view the CPU utilization, click on the Monitoring folder and then the CPU Utilization link:

Figure 7- 5. CPU Utilization window

The following field can be set:

Parameter Description

Time Interval <1s>

Select the desired setting between 1s and 60s, where “s” stands for seconds. The

default value is one second.

Record Number

<200>

Select number of times the Switch will be polled between 20 and 200. The default

value is 200.

Show/Hide

Check to display Utilization.

158
