![D-Link DGS-3212SR [205/224] Commander switch icon](/views2/1043852/page205/bgcd.png)
DGS-3212SR Stackable Gigabit Layer 2 Switch
Remote Port No.
Displays the number of the physical port on the MS or CaS that the CS is connected
to. The CS will have no entry in this field.
Local Port No.
Displays the number of the physical port on the CS that the MS or CaS is connected
to. The CS will have no entry in this field.
Port Speed
Displays the connection speed between the CS and the MS or CaS
Commander Switch Icon
Figure 9- 10. Right-clicking a Commander Icon
The following options may appear for the user to configure:
Collapse - To collapse the group that will be represented by a single icon. •
•
•
Expand - To expand the SIM group, in detail.
Property - To pop up a window to display the group information.
Figure 9- 11. Property dialog box
193
