DGS-3212SR Stackable Gigabit Layer 2 Switch

Management Options

The system may be managed out-of-band through the console port on the front panel or in-band using Telnet, a web

browser or SNMP-based management.

Web-based Management Interface

After you have successfully installed the Switch, you can configure the Switch, monitor the LED panel, and display

statistics graphically using a web browser, such as Opera, Netscape Navigator (version 6.2 and higher) or Microsoft®

Internet Explorer (version 5.0).

NOTE: To access the Switch through a web browser, the computer running the

web browser must have IP-based network access to the Switch.

Command Line Console Interface through the Serial Port or Telnet

You can also connect a computer or terminal to the serial console port or use Telnet to access the Switch. The command-

line-driven interface provides complete access to all Switch management features. For a full list of commands, see the

Command Line Reference Manual, which is included on the documentation CD.

SNMP-Based Management

You can manage the Switch with an SNMP-compatible console program. The Switch is supports SNMP version 1.0,

version 2.0 and version 3.0. The SNMP agent decodes the incoming SNMP messages and responds to requests with MIB

objects stored in the database. The SNMP agent updates the MIB objects to generate statistics and counters.

The Switch supports a comprehensive set of MIB extensions:

• RFC 1643 Ether-like MIB

• RFC 1724 RIPv2 MIB

• RFC 1757 RMON

• RFC 1850 OSPF MIB

• RFC 1907 SNMPv2 MIB

• RFC 2021 RMON II MIB

• RFC 2096 IP-FORWARD MIB

• RFC 2233 IF-MIB

• RFC 2358 Ethernet-Link MIB

• RFC 2573 SNMP Notification and Target MIB

• RFC 2574 SNMP User-based SM MIB

• RFC 2575 SNMP View-based ACM MIB

• RFC 2674 802.1p and 802.1q Bridge MIB

• RFC 2737 Entity MIB

• RFC 2932 IPMROUTE STD MIB

• RFC 2933 IGMP MIB

• RFC 2934 PIM MIB

• IEEE8021-PAE 802.1x PAE MIB

• D-Link Enterprise MIB
