DGS-3212SR Stackable Gigabit Layer 2 Switch

port and using the CLI stacking configuration command. Before stacking has been enabled on the slaves, the

IEEE 1394 port is treated logically as an individual 1000BASE port in full-duplex mode. Since the Spanning Tree

Protocol is disabled by default, a broadcast storm will result if the stacking link is completed between Switches

that have not been properly configured.

NOTICE: The CLI stacking command set for the DGS-3212SR is slightly different

from the CLI stacking command set for the DES-3226S. Please refer to the CLI

Reference Manual for each Switch for details or read the instructions starting with

the next section.
