DGS-3212SR Stackable Gigabit Layer 2 Switch

Commander switch of other group

Layer 2 member switch

Layer 3 member switch

Member switch of other group

Layer 2 candidate switch

Layer 3 candidate switch

Unknown device

Non-SIM devices

189
