DGS-3212SR Stackable Gigabit Layer 2 Switch

Parameter Description

VLAN ID (VID)

This is the VLAN ID that, along with the VLAN name, identifies the VLAN where the

multicast router is attached.

VLAN Name

This is the name of the VLAN where the multicast router is attached.

Unit

This is the Unit ID of the Switch in a Switch stack for which you are creating an entry

into the Switch’s static router port table.

Member Ports

There are the ports on the Switch that will have a multicast router attached to them.

Click Apply to implement changes made.
