Delta Electronics R1-EC5621 [17/49] Chapter 5 cia402 drive profile
![Delta Electronics R1-EC5621 [17/49] Chapter 5 cia402 drive profile](/views2/1478403/page17/bg11.png)
October, 2014 5-1
Chapter 5 CiA402 Drive Profile
5.1 Operation Mode
R1-EC5621 supports the following operation modes:
• Profile Position Mode
• Homing Mode
• Cyclic Sync Position Mode
5.1.1 Related Objects
Index
Sub
Index
Name
Access
PDO
Mapping
Units
Type
6060h
-
Modes of operation
RW
NO
-
SINT
6061h
-
Modes of operation display
RO
NO
-
SINT
6502h
-
Supported drive modes
RO
NO
-
UDINT
5.1.2 Switching Operation Modes
Operation modes can be switched via 6060h. The host station is in charge of
synchronously updating all data of operation modes. If the host station switches to
another operation mode, R1-EC5621 will immediately switch to the given mode. The
following table illustrates the behavior during switching modes.
New Operation Mode
Behavior when Switching to a New Operation Mode
Profile Position Mode
Controlword bit4 = 0→Operation mode is changed, but motor will be
stopped.
Controlword bit4 = 1→New positioning will be started immediately.
Homing Mode
Controlword bit4 = 0→Operation mode is changed, but motor will be
stopped.
Controlword bit4 = 1→Homing will be started immediately.
Cyclic Sync Position Mode
New operation mode will be started immediately.
