Chapter 2 Specifications R1-EC5621 User Guide
2-2 October, 2014
2.2 Specifications and Dimensions of R1-EC5621
2.2.1 Electrical Specifications
Item
R1-EC5621
Differential Signal Output
1 Channel (PA+, PA-, PB+, PB-)
Differential Signal Input
1 Channel (QA+, QA-, QB+, QB-, QZ+, QZ-)
Power Supply
via E-bus
Voltage of Differential
Signal
RS422 Level
Max. Output Current of
Differential Signal
RS422 Standard
Range of Pulse Output
Frequency
1 Hz ~ 4 MHz
Digital Input 24 V
4 Points (MEL, PEL, ORG, ALM)
Digital Output 24 V
2 Points (CLR, SON)
Active Level (ON > OFF)
＜8 VDC
Active Level (OFF > ON)
＞16.5 VDC
Permissible Current
30 mA
E-bus Current Draw
150 mA
Electrical isolation
500 Vrms (E-bus/ Signal Voltage)
Bit Width during Mapping
32 DI/O (1x16 bit, 1x16 bit Control/Status)
Vibration/Shock
Resistance
Conforms to EN 60068-2-6 / EN 60068-2-27/29
Noise Immunity
ESD (IEC 61131-2, IEC 61000-4-2): 8 KV Air Discharge
EFT (IEC 61131-2, IEC 61000-4-4): Power Line: 2 KV,
Communication I/O: 1 KV
RS (IEC 61131-2, IEC 61000-4-3): 80 MHz ~ 1 GHz, 10 V/m
Ambient Temperature
Operation: 0℃ ~ 50℃; Storage: -20℃ ~ 70℃
