R1-EC5621 User Guide Chapter 6 Object Dictionary
October, 2014 6-9
6.6.3 Statusword (6041h)
Statusword indicates the current status of the module.
Statusword bits include current module status and status of current operation mode.
Index
Sub
Index
Name
Data Type
Access
PDO Mapping
Value
EEPROM
6041h
0
Statusword
UINT
RO
Yes
0
No
Statusword Bits
Bit
Status
Description
0
Ready to Switch On
See <Details on Bits 0 to 6>.
1
Switched On
2
Operation Enabled
3
Fault
4
Voltage Enabled
5
Quick Stop
6
Switch on Disabled
7
Reserved
-
8
Accelerate and Decelerate
See <Details on Bits 8 and 10>.
9
Remote
Controlword (6040h) is processed
10
Target Reached
See <Details on Bits 8 and 10>.
11
Internal Limit Active
-
12
Reserved
-
13
Reserved
-
14
+EL
See <Details on Bits 14.15>.
15
-EL
<Details on Bits 0 to 7>
• Bit 0 to 7: Current status of the module
Bit6
Bit5
Bit4
Bit3
Bit2
Bit1
Bit0
Drive State
0
-
-
0
0
0
0
Not Ready to Switch On
1
-
-
0
0
0
0
Switch on Disabled
0
1
-
0
0
0
1
Ready to Switch On
0
1
-
0
0
1
1
Switched On
0
1
-
0
1
1
1
Operation Enabled
0
0
-
0
1
1
1
Quick Stop Active
0
-
-
1
1
1
1
Fault Reaction Active
0
-
-
1
0
0
0
Fault
-
-
1
-
-
-
-
Main Power On
