Chapter 6 Object Dictionary R1-EC5621 User Guide
6-4 October, 2014
6.4 Sync Manager Communication Objects
6.4.1 Sync Manager Communication Type (1C00h)
Index
Sub
Index
Name
Data
Type
Access
PDO
Map-
ping
Value
EEP-
ROM
1C00h
0
Number of used sync
manager channels
USINT
RO
No
4
No
1
Communication type
sync manager 0
USINT
RO
No
1: mailbox receive
(Master to slave)
No
2
Communication type
sync manager 1
USINT
RO
No
2: mailbox send
(Slave to master)
No
3
Communication type
sync manager 2
USINT
RO
No
3: process data
output
(Master to slave)
No
4
Communication type
sync manager 3
USINT
RO
No
4: process data
input
(Slave to master)
No
6.4.2 Sync Manager PDO Assignment (1C12h to 1C13h)
Index
Sub
Index
Name
Data
Type
Access
PDO
Mapping
Value
EEP-
ROM
1C12h
0
Number of assigned PDOs
USINT
RW
No
1
Yes
1
PDO mapping object index of
assigned RxPDO 1
UINT
RW
No
1601h
Yes
1C13h
0
Number of assigned PDOs
USINT
RW
No
1
Yes
1
PDO mapping object index of
assigned TxPDO 1
UINT
RW
No
1A00h
Yes
