October, 2014 7-1
Chapter 7 SDO Error Message
Abort Codes
7.1 SDO Error Message Abort Codes
The following table lists the SDO error message abort codes.
Abort Code
Description
0x05 03 00 00
Toggle bit not alternated.
0x05 04 00 00
SDO protocol timeout.
0x05 04 00 01
Client/server command specifier not valid or unknown.
0x05 04 00 05
Out of memory.
0x06 01 00 05
Unsupported access to an object.
0x06 01 00 00
Attempt to read an object.
0x06 03 00 02
Attempt to write a read-only object.
0x06 02 00 00
Object does not exist in the object dictionary.
0x06 04 00 41
Object cannot be mapped to the PDO.
0x06 04 00 42
The number and length of the objects to be mapped would
exceed PDO length.
0x06 04 00 43
General parameter incompatibility.
0x06 04 00 47
General internal error in device.
0x06 06 00 00
Access failed due to a hardware error.
0x06 07 00 10
Data type does not match; length of service parameter does
not match.
0x06 07 00 12
Data type does not match; length of service parameter too
high.
0x06 07 00 13
Data type does not match; length of service parameter too
low.
0x06 09 00 11
Sub-index does not exist.
0x06 09 00 30
Value range of parameter exceeded (only for write access).
0x06 09 00 31
Value of parameter written too high.
0x06 09 00 32
Value of parameter written too low.
0x06 09 00 36
Maximum value is less than minimum value.
0x08 00 00 00
General error.
0x08 00 00 20
Data cannot be transferred or stored in the application.
0x08 00 00 21
Data cannot be transferred or stored in the application
because of local control.
0x08 00 00 22
Data cannot be transferred or stored in the application
because of present device state.
0x08 00 00 23
Object dictionary dynamic generation fails or no object
dictionary is present.
