R1-EC5621 User Guide Chapter 6 Object Dictionary
October, 2014 6-3
6.3 PDO Mapping Objects
EtherCAT in CANopen protocol allows users to map objects to process data objects
(PDO) and use these PDOs to conduct data transmission.
6.3.1 Receive PDO Mapping (1601h)
Index
Sub
Index
Name
Data
Type
Access
PDO
Mapping
Value
EEPROM
1601h
0
Number of objects
in this PDO
USINT
RO
No
2
No
1
Mapping entry 1
UDINT
RW
No
0 to 0xFFFFFFFF
(Default:0x60400010)
No
2
Mapping entry 2
UDINT
RW
No
0 to 0xFFFFFFFF
(Default:0x607A0020)
No
6.3.2 Transmit PDO Mapping (1A00h)
Index
Sub
Index
Name
Data
Type
Access
PDO
Map-
ping
Value
EEP-
ROM
1A00h
0
Number of objects
in this PDO
USINT
RO
No
2
No
1
Mapping entry 1
UDINT
RW
No
0 to 0xFFFFFFFF
(Default:0x60410010)
No
2
Mapping entry 2
UDINT
RW
No
0 to 0xFFFFFFFF
(Default:0x60640020)
No
