R1-EC5621 User Guide Chapter 6 Object Dictionary
October, 2014 6-17
6.9 Position Control Function
6.9.1 Position Demand Value (6062h)
This object shall provide the demanded position value.
Index
Sub
Index
Name
Data Type
Access
PDO
Mapping
Value
EEP-
ROM
6062h
0
Position demand value
DINT
RO
No
– [Pos. unit]
No
6.9.2 Position Actual Value (6064h)
This object shall provide actual value of position measurement of the module.
Index
Sub
Index
Name
Data Type
Access
PDO
Mapping
Value
EEP-
ROM
6064h
0
Position actual value
DINT
RO
No
– [Pos. unit]
No
6.10 Profile Velocity Mode
6.10.1 Velocity Actual Value (606Ch)
This object shall provide the actual value of velocity.
Index
Sub
Index
Name
Data
Type
Access
PDO
Mapping
Value
EEPROM
606Ch
0
Velocity actual value
DINT
RO
No
– [Vel. unit]
No
6.10.2 Target Velocity (60FFh)
This object shall indicate the configured target velocity in Profile Velocity and Cyclic
Synchronous Velocity according to the user-defined value
Index
Sub
Index
Name
Data
Type
Access
PDO
Mapping
Value
EEPROM
60FFh
0
Target velocity
DINT
RW
No
–2147483648 to
+2147483647
(Default: 0) [Vel. unit]
No
