Chapter 6 Object Dictionary R1-EC5621 User Guide
6-10 October, 2014
<Details on Bit 11>
• Bit11: Internal limit active
Internal limit is active under the following condition:
• +EL/-EL signals are activated
<Details on Bits 8 and 10>
• Bit 8 and10: PP Mode
Bit No
Description
Value
Definition
8
Accelerate and
Decelerate
0
Acceleration or Deceleration Phase
1
Stage at Constant Speed
10
Target reached
0
Halt (Bit 8 in Controlword) = 0: Target Position Not
Reached
Halt (Bit 8 in Controlword) = 1: Axis Decelerates
1
Halt (Bit 8 in Controlword) = 0: Target Position Reached
Halt (Bit 8 in Controlword) = 1: Velocity of Axis is 0
• Bit 8 and 10: Homing Mode
Bit No
Description
Value
Definition
8
Accelerate and
Decelerate
0
Acceleration or Deceleration Phase
1
Stage at Constant Speed
10
Target reached
0
Halt (Bit 8 in Controlword) = 0: Target Position Not
Reached
Halt (Bit 8 in Controlword) = 1: Axis Decelerates
1
Halt (Bit 8 in Controlword) = 0: Target Position Reached
Halt (Bit 8 in Controlword) = 1: Velocity of Axis is 0
<Details on Bit 14.15>
Bit No
Description
Value
Definition
14
Positive Limit Switch
0
Positive Limit Switch is OFF
1
Positive Limit Switch is ON
15
Negative Limit Switch
0
Negative Limit Switch is OFF
1
Negative Limit Switch is ON
