R1-EC5621 User Guide Chapter 6 Object Dictionary
October, 2014 6-7
6.6 Device Control
6.6.1 Error Code (603Fh)
This object shall provide the error code of the last alarm or warning, which occurred in
R1-EC5621.
Index
Sub
Index
Name
Data Type
Access
PDO Mapping
Value
EEPROM
603Fh
0
Error code
UINT
RO
No
0
No
6.6.2 Controlword (6040h)
This object shall indicate the module status, including control of operating modes and
manufacturer-defined operation.
Index
Sub
Index
Name
Data
Type
Access
PDO
Mapping
Value
EEPROM
6040h
0
Controlword
UINT
RW
Yes
0 to 0xFFFF(Default: 0)
No
Controlword Bits
Bit No
Function
Description
0
Switch on
See <Details on Bits 0 to 3>.
1
Enable voltage
2
Quick stop
3
Enable operation
4 to 6
– (Reserved)
See <Details on Bits 4 to 9>.
7
Fault reset
8
Halt
9 to 15
– (Reserved)
<Details on Bits 0 to 3>
• Bit 0 to 3: Control commands of the module status
Command
Bits of the Controlword
Bit7
Bit3
Bit2
Bit1
Bit0
Shutdown
0
-
1
1
0
Switch on
0
0
1
1
1
Switch on + Enable
operation
0
1
1
1
1
Quick stop
0
-
0
1
-
Disable operation
0
0
1
1
1
Enable operation
0
1
1
1
1
Fault reset
0→1
-
-
-
-
