R1-EC5621 User Guide Chapter 6 Object Dictionary
October, 2014 6-15
6.8 Homing Mode
6.8.1 Home Offset (607Ch)
This object shall indicate the configured difference between the zero position for the
application and the machine home position (found during homing). During homing, the
machine home position is found and once the homing is completed, the zero position
is offset from the home position by adding the home offset to the home position.
Index
Sub
Index
Name
Data
Type
Access
PDO Mapping
Value
EEP-
ROM
607Ch
0
Home offset
DINT
RW
No
–536870912 to
+536870911
(Default: 0) [Pos. unit]
No
6.8.2 Homing Method (6098h)
This object shall indicate the configured homing method that shall be used. Please
refer to Chapter 5.2.3 Homing.
Index
Sub
Index
Name
Data
Type
Access
PDO
Mapping
Value
EEPROM
6098h
0
Homing method
SINT
RW
No
0 to 35 (Default: 35)
No
Data Description
Value (Method)
Data Description
0
No homing operation required
1
Homing on the negative limit switch and index pulse
2
Homing on the positive limit switch and index pulse
3 to 4
Homing on the positive home switch and index pulse
5 to 6
Homing on the negative home switch and index pulse
7 to 14
Homing on the home switch and index pulse
17
Homing on the negative limit switch and index pulse
Same homing as Method 1 (without an index pulse)
18
Homing on the positive limit switch and index pulse
Same homing as Method 2 (without an index pulse)
19 to 20
Homing on the positive home switch and index pulse
Same homing as Method 3.4 (without an index pulse)
21 to 22
Homing on the negative home switch and index pulse
Same homing as Method 5.6 (without an index pulse)
23 to 30
Homing on the home switch and index pulse
Same homing as Method 7~14 (without an index pulse)
33, 34
Homing on index pulse
35
Homing on the current position
