Chapter 5 CiA402 Drive Profile R1-EC5621 User Guide
5-4 October, 2014
5.2.3 Homing
The block diagram below shows the input and output objects of homing mode. Users
may specify the speed, acceleration, and method of homing. There is a further object
home offset which allows user to displace zero in the user’s coordinate system from the
home position.
Figure 5.3 Block Diagram of Homing Mode
Related Objects
Index
Sub
Index
Name
Access
PDO
Mapping
Units
Data
Type
2010h
-
Home special mode
RW
No
-
UINT
6040h
-
Controlword
RW
Yes
-
UINT
6041h
-
Statusword
RO
Yes
-
UINT
607Ch
-
Home offset
RW
No
Pos Units
DINT
6098h
-
Homing method
RW
No
-
SINT
6099h
-
Homing speeds
-
-
-
-
1
Speed during search for switch
RW
No
Vel Units
UDINT
2
Speed during search for zero
RW
No
Vel Units
UDINT
609Ah
-
Homing acceleration
RW
No
Acc Units
UDINT
Homing
Method
Controlword (6040h)
Homing Method (6098h)
Homing Speeds (6099h)
Homing Acceleration (609Ah)
Homing Offset (607Ch)
Statusword (6041h)
Position Actual Value
(6064h)
Home special mode (2010h)
