Chapter 6 Object Dictionary R1-EC5621 User Guide
6-8 October, 2014
<Details on Bits 4 to 8>
• Bit 4: PP mode control bits
Bit4
Definition
0→1
Start the next positioning after the current positioning completes (target reached)
• Bit 6 and 8: PP mode Control bits
Bit
Function
Value
Definition
6
Abs/rel
0
Target position is an absolute value.
1
Target position is a relative value.
8
Halt
0
Positioning is executed or continued.
1
Stop axis with profile deceleration
• Bit 4 and 8: Homing mode Control bits
Bit
Function
Value
Definition
4
Homing operation start
0
Do not start homing procedure
1
Start or continue homing procedure
8
Halt
0
Execute the instruction of bit 4
1
Stop axis with homing deceleration
