Chapter 6 Object Dictionary R1-EC5621 User Guide
6-18 October, 2014
6.11 Touch Probe Function
6.11.1 Touch Probe Function (60B8h)
This object shall indicate the configured function of the touch probe.
Index
Sub
Index
Name
Data
Type
Access
PDO
Mapping
Value
EEP-
ROM
60B8h
0
Touch probe function
UINT
RW
No
0 to 0xFFFF
No
Data Description
Bit
Value
Data Description
0
0
Switch off touch probe
1
Enable touch probe
1
0
Single trigger mode
1
Continuous trigger mode
2
0
Triggers with the ORG signal
1
Triggers with the QZ signal
3
–
Reserved
4
0
Switch off sampling at touch probe
1
Enable sampling at touch probe
5 to 15
–
Reserved
In homing mode, touch probe function is disabled; if touch probe function is enabled,
touch probe will be prohibited.
6.11.2 Touch Probe Status (60B9h)
This object shall provide the status of touch probe
Index
Sub
Index
Name
Data
Type
Access
PDO Mapping
Value
EEPROM
60B9h
0
Touch probe status
UINT
RO
No
-
No
Data Description
Bit
Value
Data Description
0
0
Touch probe 1 is switched off
1
Touch probe 1 is enabled
1
0
Touch probe 1 no value stored
1
Touch probe 1 value stored
2 to 15
0
Reserved
