Chapter 6 Object Dictionary R1-EC5621 User Guide
6-2 October, 2014
6.2 General Objects
6.2.1 Device Type (1000h)
This object shall indicate the type of device and its functionality.
Index
Sub
Index
Name
Data
Type
Access
PDO
Mapping
Value
EEPROM
1000h
0
Device type
UDINT
RO
No
0x00040192
No
Additional information (bit0~15): 0004 (stepping motor)
General Information (bit16~31): 0192 (DS402)
6.2.2 Error Register (1001h)
This object is an error register for the device. The value of this object is stored in the
Emergency message.
Index
Sub
Index
Name
Data Type
Access
PDO
Mapping
Value
EEPROM
1001h
0
Error register
USINT
RO
No
0x00
No
6.2.3 Manufacturer Device Name (1008h)
This object shall acquire the device name of R1-EC5621.
Index
Sub
Index
Name
Data
Type
Access
PDO
Mapping
Value
EEP-
ROM
1008h
0
Manufacturer device name
STRING
RO
No
-
No
6.2.4 Manufacturer Software Version (100Ah)
This object shall acquire information about the software version of R1-EC8124.
Index
Sub
Index
Name
Data
Type
Access
PDO
Mapping
Value
EEP-
ROM
100Ah
0
Manufacturer software version
STRING
RO
No
-
No
The current version is 1.10.
6.2.5 Identity Object (1018h)
This object shall acquire basic information about the device.
Index
Sub
Index
Name
Data
Type
Access
PDO
Mapping
Value
EEPROM
1018h
0
Number of
entries
USINT
RO
No
4
No
1
Vendor ID
UDINT
RO
No
0x00001A05
Yes
2
Product code
UDINT
RO
No
0x00005621
Yes
3
Revision number
UDINT
RO
No
0x00100000
Yes
4
Serial number
UDINT
RO
No
0x00000000
Yes
