October, 2014 3-1
Chapter 3 Product Description
3.1 Description of Each Part
Figure 3.1 Identification of Each Part
No.
Description
A
Single-Axis IO Signal Port
B
Single-Axis IO Port
C
(Part A) Single-Axis IO Signal Indicator
D
(Part B) Single-Axis IO Signal Indicator
E
Product ID Number
F
Status Indicator
G
Power Indicator
H
E-BUS Input Port
A
B
F
G
D
C
E
H
