Chapter 6 Object Dictionary R1-EC5621 User Guide
6-14 October, 2014
6.7.4 Profile Velocity (6081h)
This object shall indicate the configured velocity normally attained at the end of the
acceleration ramp.
Index
Sub
Index
Name
Data
Type
Access
PDO
Mapping
Value
EEP-
ROM
6081h
0
Profile velocity
UDINT
RW
No
0 to 4294967295
(Default: 0) [Vel. unit]
No
6.7.5 Profile Acceleration (6083h)
This object shall indicate the configured acceleration of Profile Modes
Index
Sub
Index
Name
Data
Type
Access
PDO
Map-
ping
Value
EEP-
ROM
6083h
0
Profile acceleration
UDINT
RW
No
0 to 4294967295
(Default: 3000) [Acc. unit]
No
6.7.6 Profile Deceleration (6084h)
This object shall indicate the configured deceleration of Profile Modes.
Index
Sub
Index
Name
Data
Type
Access
PDO
Map-
ping
Value
EEP-
ROM
6084h
0
Profile deceleration
UDINT
RW
No
0 to 4294967295
(Default: 3000) [Acc. unit]
No
6.7.7 Quick Stop Deceleration (6085h)
This object shall indicate the configured deceleration used to stop the motor when the
quick stop function is activated.
Index
Sub
Index
Name
Data
Type
Access
PDO
Map-
ping
Value
EEP-
ROM
6085h
0
Quick stop
deceleration
UDINT
RW
No
0 to 4294967295
(Default: 3000) [Acc. unit]
No
6.7.8 Motion profile type (6086h)
This object shall indicate the configured type of motion profile used to perform a profiled
motion.
Index
Sub
Index
Name
Data
Type
Access
PDO
Mapping
Value
EEPROM
6086h
0
Motion profile type
INT
RW
No
0 to 1 (Default: 0)
No
Data Description
Data
Data Meaning
0
T-Curve
1
S-Curve
