R1-EC5621 User Guide Chapter 6 Object Dictionary
October, 2014 6-13
6.7 Profile Position Mode
6.7.1 Target Position (607Ah)
This object shall indicate the target position of PP mode and CSP mode. In PP mode,
the value of this object shall be interpreted as absolute or relative depending on the
abs/rel flag in the controlword. In addition, in CSP mode, the value of this object will be
absolute only.
Index
Sub
Index
Name
Data
Type
Access
PDO
Mapping
Value
EEPROM
607Ah
0
Target position
DINT
RW
Yes
–2147483648 to
+2147483647
(Default: 0) [Pos. unit]
No
6.7.2 Software Position Limit (607Dh)
This object shall indicate the configured maximal and minimal software position limits.
These parameters shall define the absolute position limits for the position demand
value and the position actual value. Every new target position shall be checked against
these limits. The limit positions shall be always relative to the machine home position.
Software position limit will be abled in the condition below:
• Homing completed
Software position limit will be disabled in the condition below:
•Min. position limit >= Max. position limit
Index
Sub
Index
Name
Data
Type
Access
PDO
Map-
ping
Value
EEP-
ROM
607Dh
0
Number of entries
USINT
RO
No
2
No
1
Min. position limit
DINT
RW
No
–536870912 to
536870911
(Default: 0) [Pos. unit]
No
2
Max. position limit
DINT
RW
No
–536870912 to
536870911
(Default: 0) [Pos. unit]
No
6.7.3 Max Profile Velocity (607Fh)
This object shall indicate the configured maximal allowed velocity in forward/reverse
direction.
Index
Sub
Index
Name
Data
Type
Access
PDO
Map-
ping
Value
EEP-
ROM
607Fh
0
Max. profile
velocity
UDINT
RW
No
0 to 4000000
(Default: 4000000) [Vel. unit]
No
