Options and Accessories
Instruments 6
6-3
Instruments
Product Description/technical specifications
Fluke 1760 Basic
without fast transient
without voltage and current
sensors
Power Quality Recorder/Analyzer
8 channels
(4 voltages/4 currents or 8 voltages)
Interfaces: 1 RS 232 interface cable,
1 USB cable,
Ethernet
1 Ethernet cable for network connection
1 crosslink Ethernet cable for direct PC connection
Memory: 2 GB Flash memory
CDROM: PQ Analyze software and SW manual, operators guide on
CDROM
1 mains cable, mains adapter set, for country specific connection
1 Getting Started Manual
1 carrying bag
Fluke 1760TR Basic
with fast transient, without voltage
and current sensors
The Fluke 1760 TR Basic includes all of the items in the Fluke 1760
Basic unit, plus.
Fast transient analysis up to 10 MHz
Fluke-1760 INTL
Fluke-1760 US
without fast transient, with voltage
and current sensors
The Fluke 1760 includes all of the items in the Fluke 1760 Basic unit,
plus.
INTL: 4 voltage probes 600 V
US: 4 voltage probes 1000 V
4 flexible current probes 1000 A/200 A
GPS time sync receiver
Fluke-1760TR INTL
Fluke-1760TR US
with fast transient, with voltage
and current sensors
The Fluke 1760 TR includes all of the items in the Fluke 1760 unit,
plus.
Fast transient analysis up to 10 MHz
Accessories
The voltage probes for various ranges between 10 V and 1000 V are available for the
instrument.
The current sensor for direct current measurement (shunt) is available for 20 mA.
The passive current clamps (ac only) are available in ranges with 1 A up to 1000 A,
2 ranges can be selected in the PQ Analyze software.
The flexible current sensors (TPS Flex) are available for ranges between 100 A and
6000 A ac; 2 ranges can be selected in the PQ Analyze software.
All probes contain a memory for calibration factors, sensor identity, and serial number
which is read automatically by the instrument. Ranges can be selected in the PQ Analyze
software.
Other measuring transducers can be connected to the inputs of these sensors.
